Features & Benefits

• Premium grade aluminum tubes, brackets, curved hoses and fittings are designed to OE specifications
• Optimally thin and lightweight aluminum tubing maximizes heat transfer capacity without compromising strength
• Aluminum construction for superior heat transfer efficiency
• Louvered aluminum fins and tubes bonded through the Nocolok furnace-brazing process (the industry standard for brazing aluminum) to ensure long-lasting performance
• All TYC condensers are vehicle tested to ensure drop-in fit ease of installation and trouble - free function
• 100% leak tested at the factory to ensure each condenser functions right out of the box
• (Where applicable) some units offer an integrated receiver / drier or integrated transmission oil cooler

Installation Tips

• Old Refrigerant must be removed from the system in accordance with local, state, and federal laws.
• Replace theA / C System O-Rings / Sealsconnected to the A/C Condenser to prevent a Refrigerant leak.
• If the new A/C Condenser does not have an integrated drier, replace theA / C Receiver Drier / Accumulatoras well. After opening your A/C System, this part becomes saturated with moisture and needs to be replaced.
• After installing the new A/C Condenser, evacuate the system for at least 45 minutes to remove any moisture. Make sure it holds vacuum for at least 5 minutes. If it does not, you may have a leak in the system. Find the leaking component and repair or replace it.
• Recharge the system with the correct amount and type of Refrigerant as specified in your Owner's Manual.
