Xb35 Computer
When two of the best names come together to create something new, good things happen. The new XB is essentially a hylux + Morimoto mash-up. The powerful AS15-G4 IC chip recognizes external system faults, such as a loose high-voltage connection, and after één misfire will turn off the power instead of potentially destroying itself.
The die-cast aluminum housing houses a 100% die-cast circuit board; this eliminates any chance of moisture damage. The AMP SuperSeal three-pin connector of TE Connectivity between the igniter and the ballast ensures the safety of this crucial output.
Compact: slim 18mm body can be mounted almost anywhere, and that's fine as they are completely sealed against the elements. There are four attachment points cast directly into their housing, no loose brackets to mess around with.
Versatile: because the ignition cord can be disconnected from the HID ballast computer, you can easily switch from AMP to D2S or vice versa (without the use of unreliable adapters). And if an igniter does break, it can be easily replaced.
Output power | 35W + / - 2% |
CURRENT OUTPUT | 85V AC |
Ignition voltage | 23KV |
Input voltage | 9-18V DC |
Input stream | 5A at startup |
OPEN CIRCUIT | Secured (< 1s) |
SHORT CIRCUIT | Secured (< 1s) |
Climate range | -40C to +85c |
Contains:
Front switches | 1x Morimoto XB35 2.0 Computers |
Detonators | 1x Morimoto XB AMP |
